Table A-1 (c) Machine Language Coding [Special Format: Branch Instruction]
Operation code
1234
JMP @(d:8,Rn) 3 00010001 11100rrr disp
JMP @(d:16,Rn) 4 00010001 11110rrr disp (H) disp (L)
BSR d:8 2 00001110 disp
BSR d:16 3 00011110 disp (H) disp (L)
JSR @Rn 2 00010001 11011rrr
JSR @aa:16 3 00011000 address (H) address (L)
JSR @(d:8,Rn) 3 00010001 11101rrr disp
JSR @(d:16,Rn) 4 00010001 11111rrr disp (H) disp (L)
RTS 1 00011001
RTD #xx:8 2 00010100 data
RTD #xx:16 3 00011100 data (H) data (L)
SCB/cc Rn,disp SCB/F 3 00000001 10111rrr disp
SCB/NE 00000110 10111rrr disp
SCB/EQ 00000111 10111rrr disp
PJMP @aa:24 4 00010011 page address (H) address (L)
PJMP @Rn 2 00010001 11000rrr
PJSR @aa:24 4 00000011 page address (H) address (L)
PJSR @Rn 2 00010001 11001rrr
PRTS 2 00010001 00011001
PRTD #xx:8 3 00010001 00010100 data
PRTD #xx:16 4 00010001 00011100 data (H) data (L)
Table A-1 (d) Machine Language Coding [Special Format: System Control Instructions]
Operation code
1234
TRAPA #xx 2 00001000 0001 #VEC
TRAP/VS 1 00001001
RTE 1 00001010
LINK FP,#xx:8 2 00010111 data
LINK FP,#xx:16 3 00011111 data (H) data (L)
UNLK FP 1 00001111
SLEEP 1 00011010
NOP 1 00000000
Instruction Byte
Instruction Byte
352
