DTEB—Data Transfer Enable Register B H'FFF5 INTC

Bit 76543210

——

Initial value 00000000

Read/Write R/W R/W R/W R/W R/W R/W R/W R/W

ICI

0 Served by CPU

1 Served by DTC

OCIA

0 Served by CPU

1 Served by DTC

OCIB

0 Served by CPU

1 Served by DTC

16-Bit FRT channel 1 16-Bit FRT channel 2

ICI

0 Served by CPU

1 Served by DTC

OCIA

0 Served by CPU

1 Served by DTC

OCIB

0 Served by CPU

1 Served by DTC

402
