Honeywell Fusion4 MSC-L User Manual

Operation - Stream Configuration
Fusion4 MSC-L Part No.: 4418309_Rev09
5 - 168 Installation & Operation Manual
Honeywell
5.14.1.5.0.5.2 Block valve opening fault
On the Stream Config . Stream n . Block valve screen, select <Block
valve opening fault>.
The Stream Config. . Stream n . Block valve opening fault screen is
displayed with the following entities.
5.14.1.5.0.5.3 Block valve closing fault
On the Stream Config . Stream n . Block valve screen, select <Block
valve closing fault>.
The Stream Config. . Stream n . Block valve closing fault screen is
displayed with the following entities.
5.14.1.5.0.5.4 Block valve feedback fault
On the Stream Config . Stream n . Block valve screen, select <Block
valve feedback fault>.
The Stream Config. . Stream n . Block valve feedback fault screen is
displayed with the following entities.
Entity Description Value range
[Alarm action]
With this entity you can configure the
alarm behavior, in case this particular
alarm occurs.
<Disabled>
<Display>
<Display shutdown>
<Display pause>
[Feedback timeout]
With this entity you can set the time in
seconds in which the product stream
block valve must give feedback to the
MSCL. If no feedback is received in
[feedback timeout] an alarm occurs
depending on
[Alarm action].
<1> s ... <255> s
(default = <15> s)
Entity Description Value range
[Alarm action]
With this entity you can configure the
alarm behavior, in case this particular
alarm occurs.
<Disabled>
<Display>
<Display shutdown>
<Display pause>
[Feedback timeout]
With this entity you can set the time in
seconds in which the product stream
block valve must give feedback to the
MSCL. If no feedback is received in
[feedback timeout] an alarm occurs
depending on
[Alarm action].
Entity Description Value range
[Alarm action]
With this entity you can configure the
alarm behavior, in case this particular
alarm occurs.
<Disabled>
<Display>
<Display shutdown>
<Display pause>
