HP MSR SERIES User Manual

10
Function menu Descri
p
tion User level
Policy
Summary
Displays QoS policy
information.
Monitor
Create
Allows you to create a QoS
policy.
Configure
Setup
Allows you to configure
classifier-behavior
associations.
Configure
Remove
Allows you to remove a QoS
policy.
Configure
Port
Policy
Summary
Displays QoS policy
application information of a
port.
Monitor
Setup
Allows you to apply a QoS
policy to a port.
Configure
Remove
Allows you to remove a QoS
policy from a port.
Configure
SNMP
(supported on
the MSR1000,
MSR93X,
MSR20,
MSR30, and
MSR50)
Setup
Displays and allows you to
refresh SNMP configuration
information and statistics.
Monitor
Allows you to configure
SNMP.
Configure
Community
Displays the brief
information of SNMP
communities.
Monitor
Allows you to create, modify
and remove an SNMP
community.
Configure
Group
Displays the brief
information of SNMP
groups.
Monitor
Allows you to create, modify
and remove an SNMP
group.
Configure
User
Displays the brief
information of SNMP users.
Monitor
Allows you to create,
modify, and remove an
SNMP user.
Configure
Trap
Displays the status (enabled
or disabled) of the SNMP
trap function and target host
information.
Monitor
Allows you to enable or
disable the SNMP trap
function; create, modify,
and remove a target host.
Configure

HP MSR SERIES Specifications

General

Product Series	MSR Series
Manufacturer	HP
Category	Network Router
Ports	Varies by model
WAN Interfaces	Varies by model
LAN Interfaces	Varies by model
VPN Support	Yes
Firewall	Yes
Dimensions	Varies by model
Weight	Varies by model
Wireless Support	Varies by model
Management	Web-based, CLI
Power Supply	Varies by model
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% non-condensing
