HP MSR SERIES User Manual

257
Table 124 Configuration items
Item Descri
p
tion
Community Name Set the SNMP community name.
Access Right
Configure SNMP NMS access right:
• Read only—The NMS can perform read-only
operations to the MIB objects when it uses this
community name to access the agent.
• Read and write—The NMS can perform both
read and write operations to the MIB objects
when it uses this community name to access the
agent.
View
Specify the view associated with the community to
limit the MIB objects that can be accessed by the
NMS.
ACL
Associate the community with a basic ACL to allow
or prohibit the access to the agent from the NMS
with the specified source IP address.
Configuring an SNMP group
Select Advanced > SNMP from the navigation tree, and then click the Group tab to enter the page as
shown in Figure 259.
Figure 259 SN
MP group
1. Click Add to enter the Add SNMP Group page.
