832

Displaying IVR play states

Select Voice Management > States and Statistics > IVR Information from the navigation tree. The IVR

Play States page appears.

Figure 871 IVR play states

Table 318 Field description

Field Descri

tion

Play Count Play times of the media file.

Play State

• Playing.

• Not playing.

Play Type

• PSTN—Called party is from PSTN.

• IP—IP address of the peer media.
