369
Item Descri
tion
Accounting
Methods
Accounting
Optional
Specify whether to enable the accounting optional function.
For an online user, with the accounting optional function disabled, if no
accounting server is available or communication with the current accounting
server fails, the user will be disconnected. However, with the accounting
optional function enabled, the user can still use the network resources in such
case, but the system will not send the accounting information of the user to the
accounting server any more.
Primary
Select the primary accounting method for PPP users.
• HWTACACS—HWTACACS accounting, which uses the HWTACACS
scheme system.
• Local—Local accounting.
• None—No accounting. The system does not perform accounting for the
users.
• RADIUS—RADIUS accounting, which uses the RADIUS scheme system.
• If you do not select any accounting method, the default accounting
method of the ISP domain will be used. The default is local accounting.
Backup
Specify whether to use local accounting as the backup accounting method.
This item is available only when you select HWTACACS or RADIUS as the
primary accounting method.
Max. Number of Users
Specify the maximum number of users the ISP domain can accommodate. If
you do not specify the maximum number, the system will not limit the number
of users of the ISP domain.
Because users might compete for resources, setting a proper limit on the
number of users of an ISP domain helps guarantee performance for the users
of the ISP domain.
Figure 366 Adding an address pool
Table 161 Configuration items
Item Descri
tion
ISP Domain Select the ISP domain for the IP address pool to be created.
IP Address Pool Number
Specify the number of the IP address pool.
If you set the IP address pool number to 1, the name of the IP address pool is
pool1.
Start IP Specify the start IP address and end IP address of the IP address pool.
