HP V1910 Switch Series User Manual

136
Configuring a VLAN
Configuration task list
Use either of the following approaches or the combination of them to configure a VLAN, as shown in
Table 49 and Table 50:
Table 49 VLAN configuration task list (approach I)
Task Remarks
Creating VLANs
Required
Create one or multiple VLANs.
Selecting VLANs
Required
Configure a subset of all existing VLANs. This step is required before
displaying, modifying, or removing a VLAN.
Modifying a VLAN
Required
Configure the untagged member ports and tagged member ports of the VLAN,
or remove the specified ports from the VLAN.
Table 50 VLAN configuration task list (approach II)
Task Remarks
Creating VLANs
Required
Create one or multiple VLANs.
Modifying ports
Required
Configure ports as the untagged members or tagged members of VLANs, or
remove ports from VLANs; configure the link type and PVID of the ports.
Creating VLANs
Select Network > VLAN from the navigation tree and click the Create tab to enter the page shown in
Figure 123.

HP V1910 Switch Series Specifications

General

Product Series	V1910
VLAN Support	Yes
QoS	Yes
Ports	8, 24, or 48 10/100/1000 ports
MAC Address Table Size	8K entries
Power Supply	Internal power supply
Jumbo Frame Support	Yes
Operating Humidity	10% to 90% (non-condensing)
