Location Set a character string to describe the physical location of the device.
SNMP Version Set the SNMP version run by the system
Return to SNMPv1 or SNMPv2c configuration task list or SNMPv3 configuration task list.
Configuring an SNMP view
Select Device > SNMP from the navigation tree, and then click the View tab to enter the page as shown
in Figure 98.
Figure 98 View page
Creating an SNMP view
1. Click Add, the Add View window appears as shown in Figure 99.
2. Type the view name and click Apply, and then you enter the page as shown in Figure 100.
Figure 99 Create an SNMP view (1)
