26
To make the downloaded software package file take effect, reboot the device.
NOTE:
The HP V1910 Switch Series does not provide an independent Boot ROM image; instead, it integrates the
Boot ROM image with the system software image file together in a software package file with the
extension name of .bin.
Examples
# Download software package file main.bin from the TFTP server and use the Boot ROM image in the
package as the startup configuration file.
<Sysname> upgrade 192.168.20.41 main.bin bootrom
# Download software package file main.bin from the TFTP server and use the system software image file
in the package as the startup configuration file.
<Sysname> upgrade 192.168.20.41 main.bin runtime
Configuration example for upgrading the system
software image at the CLI
Network requirements
As shown in Figure 15, a V1910 switch is connected to the PC through the console cable, and connected
to the gateway through GigabitEthernet 1/0/1. The IP address of the gateway is 192.168.1.1/24, and
that of the TFTP server where the system software image (suppose its name is SwitchV1910.bin) is located
is 192.168.10.1/24. The gateway and the switch can reach each other.
The administrator upgrades the Boot ROM image and the system software image file of the V1910 switch
through the PC and sets the IP address of the switch to 192.168.1.2/24.
Figure 15 Network diagram for upgrading the system software image of the V1910 switch at the CLI
Configuration procedure
1. Run the TFTP server program on the TFTP server, and specify the path of the file to be loaded.
(Omitted)
2. Perform the following configurations on the switch.
# Configure the IP address of VLAN-interface 1 of the switch as 192.168.1.2/24, and specify the default
g a t e w a y a s 192.168 .1.1.
<Switch> ipsetup ip-address 192.168.1.2 24 default-gateway 192.168.1.1
# Download the software package file SwitchV1910.bin on the TFTP server to the switch, and upgrade
the system software image in the package.
<Switch> upgrade 192.168.10.1 SwitchV1910.bin runtime
File will be transferred in binary mode
Downloading file from remote TFTP server, please wait.../
TFTP: 10262144 bytes received in 71 second(s)
