HP V1910 Switch Series User Manual

53
Figure 38 Set system logs related parameters
Table 14 Syslog configuration items
Item Descri
p
tion
Buffer Capacity Set the number of logs that can be stored in the log buffer.
Refresh Interval
Set the refresh period on the log information displayed on the web interface.
You can select manual refresh or automatic refresh:
 Manual—You need to click Refresh to refresh the Web interface when displaying
log information.
 Automatic—You can select to refresh the Web interface every 1 minute, 5
minutes, or 10 minutes.
Return to Log management configuration task list.
Displaying syslog
Select Device > Syslog from the navigation tree to enter the syslog display page, as shown in Figure 39.

HP V1910 Switch Series Specifications

General

Product Series	V1910
VLAN Support	Yes
QoS	Yes
Ports	8, 24, or 48 10/100/1000 ports
MAC Address Table Size	8K entries
Power Supply	Internal power supply
Jumbo Frame Support	Yes
Operating Humidity	10% to 90% (non-condensing)
