Configuring traffic mirroring and traffic redirecting for a traffic
behavior
Select QoS > Behavior from the navigation tree and click Port Setup to enter the port setup page for a
traffic behavior, as shown in Figure 400.
Figure 400 Port setup page for a traffic behavior
Table 166 describes the traffic mirroring and traffic redirecting configuration items.
Table 166 Traffic mirroring and traffic redirecting configuration items
Item Descri
p
tion
Please select a behavior Select an existing behavior in the drop-down list.
Redirect Set the action of redirecting traffic to the specified destination port.
Please select a port
Specify the port to be configured as the destination port of traffic mirroring or
traffic directing on the chassis front panel.
Return to QoS policy configuration task list.
