Creating an IPv4 ACL
Select QoS > ACL IPv4 from the navigation tree and then select the Create tab to enter the IPv4 ACL
configuration page, as shown in Figure 383.
Figure 383 The page for creating an IPv4 ACL
Table 149 describes the configuration items for creating an IPv4 ACL.
Table 149 IPv4 ACL configuration items
Item Descri
tion
ACL Number
Set the number of the IPv4 ACL.
Match Order
Set the match order of the ACL. Available values are:
 Config—Compare packets against ACL rules in the order that the rules are
configured.
 Auto—Compares packets against ACL rules in the depth-first match order.
Return to IPv4 ACL configuration task list.
Configuring a rule for a basic IPv4 ACL
Select QoS > ACL IPv4 from the navigation tree and then select the Basic Setup tab to enter the rule
configuration page for a basic IPv4 ACL, as shown in Figure 384.
