HP V1910 Switch Series - Creating a Mirroring Group

75
Table 20 Local port mirroring configuration task list
Task Remarks
Create a local mirroring group
Required
For more information, see “Creating a mirroring group.”
Configure the mirroring ports
Required
For more information, see “Configuring ports for a mirroring group.”
During configuration, you need to select the port type Mirror Port. You
can configure multiple mirroring ports for a mirroring group.
Configure the monitor port
Required
For more information, see “Configuring ports for a mirroring group.”
During configuration, you need to select the port type Monitor Port. You
can configure one only monitor port for a mirroring group.
Creating a mirroring group
Select Device > Port Mirroring from the navigation tree and click Create to enter the page for creating a
mirroring group, as shown in Figure 59.
Figure 59 Create a mirroring group
Table 21 Configuration items of creating a mirroring group
Item Descri
p
tion
Mirroring Group ID ID of the mirroring group to be created
Type
Specify the type of the mirroring group to be created:
 Local: Creates a local mirroring group.
