HP V1910 Switch Series User Manual

276
Table 107 DHCP server group configuration items
Item Descri
p
tion
Server Group ID
Type the ID of a DHCP server group.
You can create up to 20 DHCP server groups.
IP Address
Type the IP address of a server in the DHCP server group.
The server IP address cannot be on the same subnet as the IP address of the DHCP
relay agent; otherwise, the client cannot obtain an IP address.
Return to DHCP relay agent configuration task list.
Enabling the DHCP relay agent on an interface
Select Network > DHCP from the navigation tree to enter the default DHCP Relay page shown in Figure
240. In the Interface Config field, the DHCP relay agent state of interfaces is displayed. Click the
icon of a specific interface to enter the page shown in Figure 242.
Figure 242 Configure a DHCP relay agent interface
Table 108 DHCP relay agent interface configuration items
Item Descri
p
tion
Interface Name This field displays the name of a specific interface.
DHCP Relay Enable or disable the DHCP relay agent on the interface.
Address Match Check
Enable or disable IP address check.
With this function enabled, the DHCP relay agent checks whether a requesting
client’s IP and MAC addresses match a binding (dynamic or static) on the
DHCP relay agent. If not, the client cannot access outside networks via the
DHCP relay agent. This prevents invalid IP address configuration.
Server Group ID
Correlate the interface with a DHCP server group.
A DHCP server group can be correlated with multiple interfaces.
Return to DHCP relay agent configuration task list.
