HP V1910 Switch Series User Manual

124
Item Descri
p
tion
Confirm Privacy Password
The confirm privacy password must be the same with the privacy
password.
ACL
Associate a basic ACL with the user to restrict the source IP address
of SNMP packets, that is, you can configure to allow or prohibit
SNMP packets with a specific source IP address, so as to allow or
prohibit the specified NMS to access the agent by using this user
name.
Return to SNMPv3 configuration task list.
Configuring SNMP trap function
1. Select Device > SNMP from the navigation tree.
2. Click the Trap tab to enter the page as shown in Figure 108.
3. On the upper part of the page, you can select to enable the SNMP trap function; on the lower part
of the page, you can configure target hosts of the SNMP traps.
4. Click Add to enter the Add Trap Target Host page, as shown in Figure 109.
Figure 108 Traps configuration
