433
Figure 404 The page for applying a policy to a port
Table 170 describes the configuration items of applying a policy to a port.
Table 170 Configuration items of applying a policy to a port
Item Descri
p
tion
Please select a policy Select a created policy in the drop-down list.
Direction
Set the direction in which the policy is to be applied.
Inbound—Applies the policy to the incoming packets of the specified ports.
Please select port(s)
Click to select ports to which the QoS policy is to be applied on the chassis front
panel.
Return to QoS policy configuration task list.
Configuring queue scheduling on a port
Select QoS > Queue from the navigation tree and click Setup to enter the queue scheduling configuration
page, as shown in Figure 405.
Figure 405 The page for configuring queue scheduling
Table 171 describes the configuration items of configuring queue scheduling on a port.
