44
version, Boot ROM version, and running time. The running time displays how long the device is up since
the last boot.
You can configure the device location and contact information on the Setup page you enter by selecting
Device > SNMP.
System resource state
The System Resource State displays the latest CPU usage and memory usage.
Recent system operation logs
Table 9 Description about the recent system operation logs
Field Descri
Time Displays the time when the system operation logs are generated.
Level Displays the severity of the system operation logs.
Description Displays the description of the system operation logs.
NOTE:
The Summary page displays up to five latest system operation lo
For more system operation logs, click More to enter the Log List pa
e. You can also enter this pa
selecting Device > Syslog. For more information, see the chapter “Log management configuration.”
Displaying device information
After logging in to the web interface, you can click the Device Information tab to enter the page
displaying the device ports. Hover the cursor over a port and the port details appears, including the port
name, type, speed, utilization, and status, as shown in Figure 32. For the description about the port
number and its color, see Figure 32. Similarly, you can view the power type and working status and the
fan working status.
