Creating a static ARP entry
Select Network > ARP Management from the navigation tree to enter the default ARP Table page shown
in Figure 267. Click Add to enter the New Static ARP Entry page. Select the Advanced Options checkbox
to expand advanced configuration items, as shown in Figure 268.
Figure 268 Add a static ARP entry
Table 114 describes the static ARP entry configuration items.
Table 114 Static ARP entry configuration items
Item Descri
p
tion
IP Address Type an IP address for the static ARP entry.
MAC Address Type a MAC address for the static ARP entry.
Advanced
Options
VLAN ID
Type a VLAN ID and specify a port for the static ARP entry.
IMPORTANT:
The VLAN ID must be the ID of the VLAN that has already been created, and the port
must belong to the VLAN. The corresponding VLAN interface must have been created.
Port
Static ARP configuration example
Network requirements
As shown in Figure 269, hosts are connected to Switch A, which is connected to Router B through
interface GigabitEthernet 1/0/1 belonging to VLAN 100. The IP address of Router B is 192.168.1.1/24.
The MAC address of Router B is 00e0-fc01-0000.
To enhance communication security between Switch A and Router B, static ARP entries need to be
configured on Switch A.
