Configuring voice VLAN globally
Optional
Configure the voice VLAN to operate in security mode and
configure the aging timer.
Configuring voice VLAN on a port
Required
Configure the voice VLAN assignment mode of a port as
automatic and enable the voice VLAN function on the port.
By default, the voice VLAN assignment mode of a port is
automatic, and the voice VLAN function is disabled on a port.
Adding OUI addresses to the OUI list
Optional
You can configure up to 16 OUI addresses.
By default, the system is configured with seven OUI addresses,
as shown in Table 58.
Configuring voice VLAN on a port working in manual voice VLAN assignment mode
Perform the tasks described in Table 62 to configure the voice VLAN function on a port working in
manual voice VLAN assignment mode.
Table 62 Configuration task list for a port in manual voice VLAN assignment mode
Task Remarks
Configuring voice VLAN globally
Optional
Configure the voice VLAN to operate in security mode and
configure the aging timer.
Assigning the port to the voice VLAN
Required
After an access port is assigned to the voice VLAN, the voice
VLAN automatically becomes the PVID of the access port.
For more information, see the chapter “VLAN configuration.”
Configuring the voice VLAN as the PVID of
a hybrid or trunk port
Optional
This task is required if the incoming voice traffic is untagged and
the link type of the receiving port is trunk or hybrid. If the
incoming voice traffic is tagged, do not perform this task.
For more information, see the chapter “Port management
configuration.”
Configuring voice VLAN on a port
Required
Configure the voice VLAN assignment mode of a port as manual
and enable the voice VLAN function on the port.
By default, the voice VLAN assignment mode of a port is
automatic, and the voice VLAN function is disabled on a port.
Adding OUI addresses to the OUI list
Optional
You can configure up to 16 OUI addresses.
By default, the system is configured with seven OUI addresses,
as shown in Table 58.
