186
Figure 166 MST region
Click Modify to enter the page shown in Figure 167.
Figure 167 Configure an MST region
Table 75 Configuration items of configuring an MST region
Item Descri
p
tion
Region Name
MST region name.
The MST region name is the bridge MAC address of the device by
default.
Revision Level Revision level of the MST region.
Manual
Instance ID
Manually add VLAN-to-MSTI mappings. Click Apply to add the
VLAN-to-MSTI mapping entries to the list below.
VLAN ID
Modulo Modulo Value
The device automatically maps 4094 VLANs to the corresponding
MSTIs based on the modulo value.
Return to MSTP configuration task list.
