Step 5 Check functions of the magnetic lock.
Table 6-16 Function commissioning
Check Method Normal Connection
Status
Troubleshooting
When the aisle door is
normally closed, check
whether there is a door
open alarm on the
ECC800-Pro.
There is no door
open alarm on the
ECC800-Pro.
If a door open alarm is
reported when the door is
closed, relocate the
magnetic lock and magnet
to minimize the deviation
until the door open alarm
is cleared.
----End
6.4.4 Commissioning an Emergency Door Release Button
Procedure
Step 1 Check the function of an emergency door release button.
Table 6-17 Function commissioning
Check Method
Normal Connection
Status
Follow-up Procedure
When the room door is
properly closed, short-
circuit the wiring
terminals NC and COM
or NO and COM on the
emergency door release
button.
The room door is opened
properly.
Remove the short-circuit
cable from the wiring
terminals NC and COM
or NO and COM on the
emergency door release
button.
----End
6.5 Video Management
6.5.1 Preparing Documentation
Before commissioning a camera, prepare the following documents in addition to
this document.
ECC800 Data Center Controller
User Manual (for ECC800-Pro) 6 Feature Description
Issue 02 (2020-09-07) Copyright © Huawei Technologies Co., Ltd. 142
