2. Add an ATS.
Table 8-16 Adding an ATS
Path Parameter Setting
Choose
System
Settings >
Device
Management
and click Add
Device. The
parameters
for adding
devices are
displayed.
Device
attribute
Select ATS from the drop-down list box.
Device Type Select ATS from the drop-down list box.
Connect To Select ECC800 from the drop-down list
box.
Communicati
ons Port
Select COM1 from the drop-down list box.
NOTE
The setting example indicates that the ATS
connects to the COM1 port on the ECC800-Pro.
If the ATS connects to another port, enter the
number of the connected port.
Device
Address
In this example, Device Address is set to 1.
During actual conguration, set the device
address for the ATS based on the actual
situation.
3. Click Test Connect to check whether the ATS connects to the ECC800-Pro
properly.
– If the ATS connects to the ECC800-Pro successfully, click Conrm. The
connected devices are displayed in the Number of connected devices
list.
– If the connection fails, check whether the ATS is properly connected to
the ECC800-Pro, whether the ATS and ECC800-Pro are running properly,
and whether the parameter settings are consistent with the ATS
parameters.
----End
8.1.7.17 How Can I Set and Add a PMAC615 AC Meter?
Prerequisites
One end of the straight-through cable has been connected to the RS485 port on
the PMAC615 AC meter, and the other end has been connected to the COM port
on the ECC800-Pro.
Context
The model of the single-phase AC meter for the lighting control box is PMAC615.
Procedure
Step 1 Set the PMAC615 communications address.
ECC800 Data Center Controller
User Manual (for ECC800-Pro) 8 FAQ
Issue 02 (2020-09-07) Copyright © Huawei Technologies Co., Ltd. 282
