Figure 8-22 Device connection
Step 3 Check the monitoring functions of the temperature sensor.
Table 8-37 Function commissioning
Check Method Normal Connection Status
Path: Monitoring >
Cabinet> IT Cabinet n > T/H
sensor n
You can view the current cabinet temperature.
----End
8.1.7.39 How Can I Set and Add a T/H Sensor (BOM Number: 33010516)?
If a T/H sensor is installed, perform the following steps to congure it.
Prerequisites
One end of the straight-through cable has been connected to the RS485_IN port
on the T/H sensor, and the other end has been connected to the COM port on the
ECC800-Pro or the UIM20A expansion module.
Context
This section describes how to set and add a T/H sensor by using the COM port on
the ECC800-Pro as an example.
Procedure
Step 1 Set the T/H sensor device address.
Set the T/H sensor device address through the DIP switch on the T/H sensor.
Toggle switches 1 to 6 of the DIP switch specify the device address in binary mode.
ON indicates 1, and OFF indicates 0.
Table 8-38 Setting a device address
Address
Toggle
Switch 1
Toggle
Switch 2
Toggle
Switch 3
Toggle
Switch 4
Toggle
Switch 5
Toggle
Switch 6
1 ON OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF
3 ON ON OFF OFF OFF OFF
4 OFF OFF ON OFF OFF OFF
