6.5.3.3 Commissioning a C3220 Camera
Prerequisites
● If multiple cameras are connected, commission one camera rst and then
commission other cameras in the same way.
● The camera has connected to the smart ETH gateway and the smart ETH
gateway communicates properly with the ECC800-Pro.
● The camera software version is later than SDC 8.0.RC111.
Context
● Before commissioning the C3220 camera, set the IP address for the C3220
camera based on customer requirements.
●
Congure the camera or VCN internal IP address and the IP address of the
LAN port on the ECC800-Pro in the same network segment.
●
Congure the camera or VCN external IP address and the IP address of the
WAN_1 port on the ECC800-Pro in the same network.
● Set the internal and external IP addresses as planned by the customer. The
following IP addresses are for reference only.
Table 6-22 IP address planning
Device
Internal IP Address External IP Address
Camera Example: 192.168.248.50; range:
192.168.248.50–192.168.248.199
Camera external IP
address
NOTE
The 192.168.246.X
network segment
cannot be set.
VCN Example: 192.168.248.51; range:
192.168.248.50–192.168.248.199
VCN external IP
address
NOTE
The 192.168.246.X
network segment
cannot be set.
Procedure
Step 1 Log in to the camera web system and enable ONVIF.
1. Remove the network cables that connect the smart ETH gateway to the LAN1
and LAN2 ports on the ECC800-Pro.
2. Use a network cable to connect the PC to the PoE port on the smart ETH
gateway. Then, set the local IP address of the PC to 192.168.0.11.
3. Remove the camera shell and press the reset button for 6s to 10s to restart
the camera.
