Indicators
Table 3-61 ETH converter indicators
Indicator Color Name Status Description
PWR Green Power input
status
indicator
Steady on The power input is normal.
O There is no power input.
RUN Green Operating
status
indicator
O The power supply is
abnormal.
Blinking at
long
intervals
The ETH converter
successfully registers with
the ECC800-Pro and the
software runs properly (the
indicator blinks at 0.5 Hz, on
for 1s and then
o for 1s).
Blinking at
short
intervals
The communication fails or
the ETH converter fails to
register with the ECC800-Pro
(the indicator blinks at 4 Hz,
on for 0.125s and then o
for 0.125s).
Blinking The indicator blinks at super
short intervals for 0.5s
(blinking at 10 Hz, on for
0.05s and then o for 0.05s)
and then turns o for 0.5s.
The cycle lasts for 10s.
ALM Red Alarm
indicator
Steady on A system failure alarm is
generated.
O No system alarm is
generated.
3.2.18 PAD
The pad allows the wireless access from the data center management system. You
can monitor the equipment in the data center and environmental parameters in
real time over the app. The recommended model is T5-10.
