Path Parameter Name Defaul
t Value
Description
QF1 Branch circuit breaker
in use (L1)
QF2 Branch circuit breaker
in use (L2)
Enable When the
parameter is set to
Disable for a
branch, all alarms of
the branch will not
be reported.
When the
parameter is set to
Enable for a branch,
all alarms of the
branch will be
reported.
Upper load current
threshold
80 When the load
current exceeds the
preset value, an
alarm is generated.
Lower load current
threshold
60 When the load
current exceeds the
preset value, an
alarm is generated.
4. Set the parameters for other power distribution units in the same way or by
synchronizing parameters.
Path: Maintenance > Parameter Sync.
----End
5.6 Commissioning the eLight
If an eLight is installed, perform the following steps to
congure it.
Procedure
Step 1 Ensure that the device address of the eLight actuator is the default value 2.
Toggle switches 1 to 4 of the DIP switch specify the device address in binary mode.
ON indicates 1, and OFF indicates 0.
Table 5-5 Setting a device address
Address
Toggle
Switch 1
Toggle
Switch 2
Toggle
Switch 3
Toggle
Switch 4
1 ON OFF OFF OFF
2 OFF ON OFF OFF
