Figure 3-24 Smoke sensor
Table 3-48 Technical specications of a smoke sensor
Item Specications
Operating voltage DC12 V (9–16 V DC)
Quiescent current < 8 mA
Alarm current < 35 mA
Output mode Relay output
Output contact capacity 3 A/120 V AC or 3 A/24 V AC
Operating temperature –10ºC to +50ºC
Ambient humidity < 95% RH (non-condensing)
Dimensions Diameter: 112 mm, height: 41 mm
3.2.10 Temperature Sensor
The temperature sensor (BOM number: 33010348) is used for the surface
temperature measure, industrial process control, measurement instrument, etc.
Figure 3-25 Temperature sensor
ECC800 Data Center Controller
User Manual (for ECC800-Pro) 3 Device Description
Issue 02 (2020-09-07) Copyright © Huawei Technologies Co., Ltd. 56
