Huawei ECC800-Pro - T;H Sensor (BOM Number: 02311 FQG)

Table 3-69 T/H sensor specications
Item Specications
Temperature measuring range –20°C to +80°C
Temperature accuracy ±0.5°C (25°C)
≤ ±1°C (full measuring range)
Operating temperature –20°C to +80°C
Operating voltage 9–16 V DC
Storage temperature –40°C to +80°C
Output Two RJ45 ports, bidirectional cascading
3.2.19.4 T/H Sensor (BOM Number: 02311FQG)
Figure 3-42 Appearance
(1) RS485-OUT
(2) RS485-IN (3) DIP switch (4) Button
(5) NTC1–3 (6) NTC4–6 (7) Display
Table 3-70 T/H sensor specications
Item
Temperature Humidity
Measurement range –40°C to +70°C 0%–100% RH
Measurement precision ≤±1°C (–20°C to
+60°C)
≤±5% RH (25°C, 20%–80%
RH)
Extended temperature
collection port
Provides two RJ45 ports to connect to six NTC
temperature sensors, each RJ45 port connecting to
three NTC temperature sensors.
