NO TE
In this example, the smoke sensor is connected to the AI/DI_1 port on the UIM20A
expansion module.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Choose Monitoring > System > UIM Group> UIM n > Running Parameters.
3. In AI/DI_1 Port Settings area, set AI/DI_1 sensor to Enable, click Submit.
4. Set AI/DI_1 sensor type to Smoke sensor, click Submit.
Step 2 Check the monitoring functions of smoke sensor.
Table 8-30 Function check
Check Method Normal Connection Status Alarm Clearance Method
Simulate a
smoky
environment
under the smoke
sensor.
Smoke sensor status(AI/
DI_1) is displayed on the
active alarm page of the app
or WebUI.
If Smoke sensor type is
Smoke Sensor, power o
and reset the smoke sensor
to clear the alarm.
----End
8.1.7.33 How Can I Set and Add the WLDS900 Water Sensor?
If a water sensor is installed, perform the following steps to congure it.
Prerequisites
One end of the straight-through cable has been connected to the RJ45 port on the
WLDS900 water sensor, and the other end has been connected to the AI/DI port
on the ECC800-Pro.
Context
● To use the AI/DI sensor, enable the corresponding AI/DI port and name the
sensor. The
specic alarm then can be reported.
● If the sensor is prefabricated, only check its settings.
● The actual value prevails. Only the method of the parameter settings is
described.
Procedure
Step 1 Set water sensor parameters.
NO TE
● In this example, the water sensor is connected to the AI/DI_1 port on the ECC800-Pro.
● The default alarm severity of the AI/DI port is Minor. If you want to change the alarm
severity, see How Should I
Congure Alarm Parameters.
1. Log in to the ECC800-Pro WebUI as an administrator.
