Path Parameter Default
Value
Setting
Default
gateway
192.168.8.1 Set this parameter based on the
default gateway address assigned by
the network administrator.
Step 3 Set SNMP parameters.
1. Choose System Settings > NMS Application > SNMP.
2. Set SNMP Version to SNMPv3 and set SNMP port number to the required
port number or retain its default value 161.
3. Click Submit under SNMP.
4. Click Add under SNMPv3.
5. Set User name, set Authentication protocol to SHA or MD5, set Privacy
protocol to AES or DES, and specify MD5/SHA password,
Conrm MD5/SHA
password, DES/AES password, and
Conrm DES/AES password.
NO TE
– Set User name, MD5/SHA password, and DES/AES password to any character
strings that meet the system requirements. Note that MD5/SHA password and
DES/AES password must be set to
dierent values. Record the settings.
– MD5 and DES are insecure protocols. Therefore, you are advised to set
Authentication protocol to SHA or set Privacy protocol to AES.
6. Set Password validity period and Advance expiration notication (days).
7. After setting the parameters, click Conrm.
8. Click Add under SNMP Trap.
9. Set Trap target address and Trap port, set SNMP version to SNMPv3, and
specify SNMPv3 user name. Set Trap target address to the IP address of the
NMS server and set Trap port to the port dened by the user.
10. After setting the parameters, click Conrm.
11. Click Export in the Mib File pane, export the MIB le, and send it to the
development engineers of the NMS.
NO TE
For enterprise users: Log in to http://support.huawei.com/enterprise, download the
software package of the required version from Support > Software Download >
Network Energy > Fusion Modular Data Center > ECC800, and decompress the
software package to obtain the MIB le.
For carrier users: Log in to http://support.huawei.com, download the software package
of the required version from Support > Software > Carrier Cloud & Data Center >
Data Center Facility > Fusion Modular Data Center > ECC800, and decompress the
software package to obtain the MIB le.
----End
6.15 Network Security Management
Choose Monitoring > System > ECC800 > Running Parameters > Unhide All
Advanced Signals > Other Parameters.
