Address Toggle Switch 1 Toggle Switch 2 Toggle Switch 3
2 ON OFF ON
NO TE
If the signal quality is poor due to signal reection caused by long communications cables
(longer than 50 m), set toggle switch 4 to ON for the furthest independent deployment AI_DI
unit. After the DIP switch settings are modied, power o and restart the independent
deployment AI_DI unit for the new settings to take
eect.
Step 2 Add an independent deployment AI_DI unit.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Add an independent deployment AI_DI unit.
Table 8-23 Adding an independent deployment AI_DI unit
Path Parameter Setting
Choose
System
Settings >
Device
Management
and click Add
Device. The
parameters
for adding
devices are
displayed.
Device
attribute
Select Independent Deployment AI_DI
Unit from the drop-down list box.
Device Type Select Independent Deployment AI_DI
Unit from the drop-down list box.
Connect To Select ECC800 from the drop-down list box.
Communica
tions Port
Select COM3 from the drop-down list box.
NOTE
The setting example indicates that the
independent deployment AI_DI unit is connected
to the COM3 port on the ECC800-Pro. If the
independent deployment AI_DI unit is connected
to another port, set the COM port to the ECC800-
Pro port connected to the independent
deployment AI_DI unit.
Device
Address
In this example, Device Address is set to 1.
During actual conguration, set the device
address for the independent deployment
AI_DI unit based on the actual situation.
3. Click Test Connect to check whether the independent deployment AI_DI unit
connects to the ECC800-Pro properly.
a. If the independent deployment AI_DI unit connects to the ECC800-Pro
successfully, click
Conrm. The connected devices are displayed in the
Number of connected devices list.
b. If the connection fails, check whether the independent deployment AI_DI
unit is properly connected to the ECC800-Pro, whether the independent
deployment AI_DI unit and ECC800-Pro are running properly, and
