Table 3-33 Specications of a ngerprint and card reader
Item Specications
Dimensions (L x W x H) 156 mm x 53 mm x 38 mm
Rated operating voltage 12 V DC±5%
Rated operating current 300 mA±5%
Card type supported IC card
Authorized storage A maximum of 3000 authorized users, with a
maximum of 6000 ngerprints
Communications mode RS485 and Wiegand communications ports
Table 3-34 Access control device operating status
Item New Version
Standby LED indicator The indicator is steady
blue.
Fingerprint reader The indicator is o.
Unauthorized ngerprint
collection
LED indicator The indicator blinks blue,
red, blue, red, and blue
in order.
Fingerprint reader The indicator turns on
(white).
Buzzer sounds The buzzer sounds three.
Authorized ngerprint
collection
LED indicator The indicator blinks blue,
red, and blue in order.
Fingerprint reader The indicator turns on
(white).
Buzzer sounds The buzzer sounds once.
Card swiping LED indicator The indicator blinks blue,
red, and blue in order.
Buzzer sounds The buzzer sounds once.
