86 Issue 3.3.2 / April, 2011
Program 05-13-IP : System Timing Parameters – 13
05-13-IP SYS PAR
0 0 0 0 0 0 0 0
IP = 01-08
System Default.
Item Display Programming Data Timing
Pointer Data Description Table Default
---------- ---------- ----------------------------------------------------------- ---------- ------------
01 0-1 Intercom Hot Key Dialling 0=No
02 0-1 Immediate SMDR output 0=Disable
03 0-1 Caller ID Buffer Block Size 0=52 Sets
04 0-9 Reserved 0=
05 0-1 CLI Record Storing Method for LCD Phones 0=No. Only
06 0-1 CTI-Trunk Status Report 0= Disable
07 0-7 Least Cost Routing( LCR) – Weekly Holiday 1 0= Disable
08 0-7 Least Cost Routing(LCR) – Weekly Holiday 2 0= Disable
Description:
01. Intercom Hot Key Dialling:
This parameter when enabled allows stations to dial a call On Hook without having to lift the handset or
press the SPK key.
0 = Disable 1= Enable
02. Immediate SMDR output
This parameter when enabled will send the SMDR output to the PC/Printer immediately a call is made.
This allows external software to know who is dialling out or who is ringing into the system at this
moment. In applications such as the Internet Cafe, when the customer dials out, the system will send out
the SMDR information immediately. The external software can then start to count the cost from the
beginning of the call. If the credit is 1 hour and time is expired, the external software could cut the
connection by sending commands back to the KSU.
0 = Disable 1= Enable
03. Caller ID Buffer Block Size
This sets the block size of the Caller ID buffer:
05-13-03 Memory Block Size Max. Memory blocks/set
0 10 sets 52
1 20 sets 26
2 30 sets 17
3 40 sets 13
Refer to Mode 83 to allocate the buffers to the use of LCD Digital Phones.
04. Reserved
