110 Issue 3.3.2 / April, 2011
Program 06-IP : Relay Assignment
06-000-01 Relay
00
IP = 01
System Default.
Item Display
Pointer Data Description
-------- -------- ---------------------------
00(00) 00-06 Relay of MSU/MSC
xxxx 00-06 Relay of ACP (extension: xxxx)
Description:
MSU/MSC card and ACP device have 1 dry contact relay.
No voltage is provided by the system, the installer will have to provide their own source to suit the
application. Only use the relays to switch 24V DC / 90V AC at 1A. They are only designed for low
voltage control circuits. All Relays are Normally Open contacts and will close on activation of the function
for which they have been programmed.
Assign the required Relays one of the following functions.
Set data Function
00 No Operation
01 Music On Hold
02 Door open
03 Reserved for future use
04 Trunk loud bell
05 Station loud bell
06 System Alarm
10 All Paging
MSU/MSC card and ACP device have 1 dry contact relay.
