176 Issue 3.3.2 / April, 2011
Program 87-CN-IP : ASSIGN DOORPHONE FOR KEY CARD
87-nn-01 Card In
000000000000000
nn = card Number 01~99
IP = 01-24 = ACP port number
General:
This program assigns which Key cards can be used on which ACP port to unlock a door.
Description:
Before a key card can be used to operate a door relay it must be enabled in this program mode. A key card can
be enabled to unlock more than one door if multiple ACP’s are fitted.
0 = Denied entry 1 = Allowed entry
G1E MBU STU 1 STU 2
Extension port
11-18 21-28 31-38
ACP port
1-8 9-16 17-24
Program 88-DP : REGISTER KEY CARD
Register Card
ST:___
Station number of ACP
General:
This program registers key cards for use.
Description:
Before a key card can be used with an ACP it must first be registered to it. Once the key card is registered then it
will be necessary to proceed to mode 87 to allow the key card to open the door relay associated with the ACP.
To register a key card enter the station number of the ACP
Register Card
ST:115
Press SAVE
Wait Registering
Slide please
Place the Key Card over the Speaker position on the ACP and when the ACP beeps remove the Key card and
press SAVE.
Register Store
Card:01
Press SAVE
Registration ok!
Card:01
