HYBREX G1E - Program 70-CD-Ip: Isdn Interface Specifications Program - G1 E

164 Issue 3.3.2 / April, 2011
Program 70-Cd-IP : ISDN Interface Specifications Program – G1E
70-Cd-IP S/T TYP
111111
Cd = 01-04, IP = 01-06
System default
General:
To assign the ISDN interface to “S” interface or “T” interface.
Description:
Cd= 01 is to assign the “S” or “T” interface for the ISDN port on G2-SIU card.
0= “S” interface. It can connect two ISDN devices. Use Program 43-CN to set the Device Station
Number (Station Type is 9).
1= “T” interface. It can be connected to “NT” interface of ISDN line.
Cd= 02 is for test purposes only.
0= Loopback disabled
1= Loopback enabled
Cd= 03 is for connection method.
0= Point to Point (recommend ‘0’ for internal ISDN S interface use if only one ISDN device
connected) Default setting
1= Point to Multi-point 2= Point to Multi-point and ignore the unknown MSN or DDI number (not
assigned in mode 72)
This application is normally for other ISDN devices (e.g. ISDN TA, ISDN video conference, ISDN
card, …) that are hooked to the NT1 with the G1E.
For Australian networks the usual connection is Point To Point. Network features such as Diversion will
only work on Point to Point on the Telstra network
Cd= 04 is for the ISDN PLL (Phase Loop Lock)
0= Auto detect
1= Lock this ISDN line for PLL. Signal.
Note:
The following table is the Cross Reference Table for physical position of ISDN interface and
programming position.
Cd
Cd=01 Cd=02 Cd=03 Cd=04
IP=01/02/03 1
st
/2
nd
/3
rd
port
of 1
st
SIU
1
st
/2
nd
/3
rd
port
of 1
st
SIU
1
st
/2
nd
/3
rd
port
of 1
st
SIU
1
st
/2
nd
/3
rd
port
of 1
st
SIU
IP
IP=04/05/06 1
st
/2
nd
/3
rd
port
of 2
nd
SIU
1
st
/2
nd
/3
rd
port
of 2
nd
SIU
1
st
/2
nd
/3
rd
port
of 2
nd
SIU
1
st
/2
nd
/3
rd
port
of 2
nd
SIU
Example:
70-01-IP S/T TYP
110111
It sets the 1
st
,2
nd
, 4
th
, 5
th
, 6
th
ISDN interface to “T” interface and 3
rd
interface to “S” interface.
The user can program the station number in program mode 43, port 61~68.
