G1E Programming Manual
159
Program (61 to 66)-code-IP : Toll Plans – Restricted Digits – Class 1 to 6
61-code-01 Restrict
dddddddddddd
Code = code no 01-16, IP = 01-12
System default
General:
This program sets Restricted numbers for Toll Class 1. These Modes should be read in conjunction with Modes
51 to 56.
Description:
There are 16 codes for each Toll Class and each code contains up to 12 digits
In default any station allocated to Toll Plans 1 to 6 will be able to dial unrestricted until the associated Modes are
programmed.
Allowed entries in this Mode are 0 to 9, d and _. d = Don't care and means that any digit can be dialled in this
position. _ = no digit is allowed to be dialled beyond this position. If a digit is allowed as the beginning of a
number then the entry should be filled with don't care's to the end of the line or the caller will not be able to dial
the full number.
Modes 51 to 56 are used in conjunction with Modes 61 to 66 and Modes 57 to 59 are used independently and do
not have an associated restriction table.
In Default stations which are allocated Toll Plans 0 to 6 are able to dial any numbers.
When a station is allocated Toll Plans 7 to 9 they can dial no digits until the plans are programmed.
Mode 51 and 61 combine to produce Toll Plan 1, Mode 52 and 62 combine to produce Toll Plan 2 and so on up
to Mode 56 and 66 for Toll Plan 6. Toll Plans 7, 8 and 9 are associated with Mode 57, 58 and 59.
The principle of these Toll Plans up to Plan 6 is to deny unwanted digits in Mode 61 to 66 and then allow any
exceptions for these digits in Mode 51 to 56. If 0ddddddd is entered in Mode 61 and 04ddddddddddd_and
01dddddddd are entered in Mode 51 then a station allocated to Toll Plan 1 will be able to dial any local number
plus 04 anything (Australian Digital and CDMA Mobile phones) . Any other number beginning with 0 will be
disallowed.
