66 Issue 3.3.2 / April, 2011
Program 05-03-IP : System Timing Parameters – 03
05-03-IP SYS PAR
0 0 1 9 0 3 0 6
IP = 01-08
System Default.
Item Display
Pointer Data Programming Data Description Default
--------- ---------- ----------------------------------------------------------- -------------
01 0-1 Make / Break Ratio 0=33/66
02 0-1 Automatic Trunk Search 0=Yes
03 0-1 Intercom Call Signalling Method 1=Ring
04 0-9,d PABX (Centrex) Outgoing Code 9=9
05 0-9 Toll Access Code 0=0
06 2-4 Station Numbering Plan 3=3
07 0-1 Internal Dial Tone Pattern 0=Steady
08 0-9 Door Phone / ACP Ringing Frequency 6= Ring Freq 6
Description:
01. Make/Break Ratio:
This parameter permits the selection of a Make/Break Ratio for Dial Pulse signalling.
0 = 33/66 1 = 40/60
02. Automatic Trunk Search:
This parameter allows the system to search for an available trunk according to the assigned dial 9 trunk
group when automatic dialling features are used; i.e., Speed Dial, Save Redial, Redial, etc.
0 = Allowed 1 = Not Allowed
03. Intercom Call Signalling Method:
This parameter selects the Intercom calling method. The user can still override this selection by dialling
3 after initiating an intercom call. Individual stations can be set to automatic microphone switch-on in
mode 46-st-03 and thus override the system wide ring method.
0 = Voice Signalling. 1 = Ring Signalling.
04. PABX (Centrex) Outgoing Code: (Refer to Program 35-TK-01):
This parameter assigns the PABX outgoing call access code for Redial and Save Redial when the
system is installed behind a PABX.
It is used when Trunk Lines are set to be PABX lines in Mode 35-TK-01.
This assignment also enables the system to identify whether the user's dialling is a PABX's Intercom call
or an Outgoing call for toll restrictions.
