HYBREX G1E - Program 43-Cn-Ip: Port Specifications

G1E Programming Manual
143
Program 43-cn-IP : Port Specifications
43-cn-IP Port
stn 0 1 0 00 02
cn = Port No. (2 digits) IP = 01-06
Parameters for the port
cn = Position Number on Card (11-68)
11~18: station port on G1E-MBU 21~28: station port on the 1
st
G1E-STU card.
31~38: station port on the 2
nd
G1E-STU or G1E-SLU card. 41~44: SLT ports on G1E-SIU MBU.
Item Display
Pointer Data Programming Data Description Default
---------- ----------- ------------------------------------------------------------ -----------
01 nnnn Station Number (2 to 4 digits) System
02 0-9 Equipment Type System
03 1-9 DSS Soft key Plan 1=1
04 0- Reserved 0=
05 00-50 Voice Mail Box Capacity 00= disabled
06 00-90 Maximum Voice Mail Message Length 01=1 Minute
General:
This program permits each port to be assigned different parameters and station numbers.
Description:
01. Station number:
Use this setting to assign station numbers for the Flexible Numbering Plan. The allowed number range is 10-69,
100-699. 1000-6999. If it is necessary to use digits 7 or 8 as part of the station numbering scheme then Mode
05-08-05 must first be set to 8 to prevent confusion between control codes/programming digits and Station
numbers.
02. Equipment type:
0 = None connected 1 = Digital Phone without LCD
2 = Digital Phone with LCD 3 =
4 = Single Line Telephone 5 = DSS
6 = Dual port 7 = SLT Port used as MOH input.
8 = Voice Mail Port 9 = ISDN Device
D = Door phone/ACP - = SLT Paging port (press [FLASH] key)
T = Fax Port (press [MSG] for T)
Types 0 to 5 and d are recognized by the system automatically.
Type 6 allows an SLT port to be paired to a Digital Extension providing a pseudo Hybrid port. Once set the SLT
phone can be given the same extension number as a Digital Extension and when the number is called both
Phones will ring. Either phone can answer and once one answers then a call to the same number will show
busy. The call can be placed on hold by one of the extensions and retrieved from the other or can be transferred
to other extensions by the normal method. The Station COS of the digital phone will be allocated to the SLT
automatically.
Type 7 allows an SLT port to be used as an additional MOH input allowing tenanted systems to have different
messages played to different trunk groups during Call Hold. Once an SLT port is set to MOH then in Mode 41-
slt-04 the port can be allocated to all or individual trunks groups as a hold source.
Type – allows the SLT port to be used for an External Paging Port.
Both SLT Music Port and SLT Paging port MUST have a line isolator unit fitted.
