HYBREX G1E - Program 05-01-IP: System Timing Parameters - 01

62 Issue 3.3.2 / April, 2011
Program 05-01-IP : System Timing Parameters – 01
05-01-IP SYS PAR
1 1 1 1 4 2 2 1
IP = 01-08
System Default.
Item Display Timing
Pointer Data Programming Data Description Table Default
----------- ---------- -------------------------------------------- ----------- ---------------
01 0-9 Hold Recall Time A 1=60 Sec.
02 0-9 Exclusive Hold Recall Time A 1=60 Sec.
03 0-9 Hold Recall Timeout A 1=60 Sec.
04 0-9 DISA & ECF Access Delay Time-Day C 1=2 Sec.
05 0-9 Busy Remind Cycle Time C 4=8 Sec.
06 0-9 Pause Time D 2=800 Ms.
07 0-9 DTMF Generation Time E 2=83 Ms.
08 0-9 Call Forward No Answer TRF. Time 1=20 Sec.
Description:
01. Hold recall time:
This parameter sets the time duration from when Hold is initiated to when the held call starts to ring
(recall) the station.
After a pre-determined recall time (see 05-01-03: Hold Recall Timeout), if the station still does not
answer, the hold call will automatically transfer to the Console.
02. Exclusive Hold recall time:
This parameter sets the time duration from when Exclusive hold is initiated to when the held call starts to
recall the station.
After a pre-determined recall time (see 05-01-03: Hold Recall Timeout), if the station still does not
answer, the held call will recall to the Console in addition to the holding station.
03. Hold Recall Timeout:
This parameter sets the time between a call recalling to a holding or transferring station and then
recalling to the console if unanswered.
See timing table Grade A for parameters of these 3 features.
04. DISA & ECF Access Delay Time - Day
This parameter sets the time duration that a DISA/ECF trunk will ring prior to connection by the system
during Day mode. Stations can answer during this time.
0 = Automatic connection, no ring to the stations.
1-8 = Automatic connection after 2-254 seconds ringing.
See timing table grade C for parameters for this feature.
See mode 05-11-04 for night and mode 05-17-4 for Lunch delay.
