128 Issue 3.3.2 / April, 2011
Program 29-tk-IP : Trunk Specifications – 2
29-tk-IP TK SPEC
0 0 0 2 0 0 0 0
tk = 01-12, IP = 01-08
System Default
Item Display
Pointer Data Programming Data Description Default
-------- ---------- ------------------------------------------------ -------------
01 0-1 Trunk Receive Gain 0= 0db
02 0-8 ACD-1 Function Enable 0=Disable
03 0~9 Trunk Transmit Gain 0= 0db
04 0-8 Set Ring Frequency (DK Handsets) 2= Frequency 2
05 0-9 Allow Audible Ring for Incoming Calls 0=All Stations
06 0-1 Polarity Reverse Detection. Individual Trunk-outgoing. 0=Disable
07 0-9 CO Delayed Ring Timer to Hunting Group 0=Disable
08 0-9 CO Delayed Ring Overflow Hunting Group 0=The 1
st
Hunting Group
General:
This program permits each trunk line to be assigned different parameters.
Description:
01. Trunk Receive Gain:
This parameter can adjust the system’s analogue TKU interface to adapt to different CO loop resistance. For
long lines where Receive audio may be low this parameter will allow Receive loudness to be boosted.
0 = 0db 1 = 1db 2 = 2db - 9 = 9 db
02. ACD-1 Function Enable:
This parameter enables or disables the ACD-1 function for each trunk individually and is able to select whether
ACD-1 operates in Day or Night or Both Modes.
0 = Day Time - Disable ACD function, Night Time - Disable ACD function
1 = Day Time - Disable ACD function, Night Time - Enable ACD function
*1
2 = Day Time - Disable ACD function, Night Time - Enable ACD function*2
3 = Day Time - Enable ACD function
*1
, Night Time - Disable ACD function
4 = Day Time - Enable ACD function
*1
, Night Time - Enable ACD function
*1
5 = Day Time - Enable ACD function
*1
, Night Time - Enable ACD function
*2
6 = Day Time - Enable ACD function
*2
, Night Time - Disable ACD function
7 = Day Time - Enable ACD function
*2
, Night Time - Enable ACD function
*1
8 = Day Time - Enable ACD function
*2
, Night Time - Enable ACD function
*2
*1: Enable ACD-1 function only when all ring assigned stations are busy.
*2: Enable ACD-1 function when 05-09-06 timer has elapsed even if ring assigned stations are idle.
03. Trunk Transmit Gain:
This parameter can adjust the system’s analogue TKU interface to adapt to different CO loop resistance. For
long lines where the Transmit audio may be low this parameter will allow Send loudness to be boosted.
0 = 0db 1 = 1db 2 = 2db - 9 = 9 db
