G1E Programming Manual
133
Program 36-gp-tk : Trunk Group Assignments
36-gp-IP TK GRP
01 02 03 04 05
gp = 01-08, IP = 01-12
trunks to be included
General:
This program permits each trunk line to be assigned to different Trunk groups. There are eight groups in total.
Description:
In the bottom data-setting area, the trunk number (01-12) means that the trunk is included in the specified group.
Press [REDIAL] to clear all entries from the table before entering the required trunks. Always set outgoing calls
to start from the highest fitted trunk and program in descending order to the lowest trunk fitted. This will prevent
call collision particularly in systems with SLT'S using PSTN trunks. An additional 8 groups are available by
utilising the groups available in Mode 38 for the dial 87 trunk groups. If a station is allocated no dial 9/0 group in
Mode 41-st-04 but is then allocated a Dial 87 group in mode 46-st-01 then this station will use that group as its
dial 9/0 group giving a total of 16 groups available.
There are 12 trunks maximum in a trunk group.
This parameter will work with the following features:
. Dial 9 or 0 access to trunk group.
. Tenant service.
Related System Programming Mode: 36, 38, 41-ST-04, 46-ST-01
