SMDR OUTPUT DATA FORMAT
ST.
TK S TELEPHONE NUMBER Account MM/DD START DURATION RING UNIT
112 01 001188629645752 12345678 10/02 08:35 00:02'35"
115 02 Incoming 87654321 10/02 08:45 00:10'20" 00'10"
000 03 Incoming no answer 10/02 12:00 00'35"
112 04 001188629645752 FAC:01 10/02 12:10 00:02'00"
112 03 X FAC or PSW error 10/02 12:30
112 05 X 001 10/02 12:35 00:00'05"
121 01 # 0294150100 10/02 14:15 00:00'55"
117 01 * 0294150100 10/02 14:15 00:03'10"
D3 05 0418220212 10/02 21:01 00:02'30"
D-03 D << D I S A OFF >> 10/02 21:00 00:02'40"
112 02 DDI Num: 94150112 10/02 08:45 00:10'20" 00'10"
03 CLI NoAns:294176288 10/02 12:00 00:00'00" 00'35"
111 05 CLI Num: 294150100 10/02 12:35 00:00'05" 00'05"
05 DDI NoAns:94150112 10/02 12:37 00:00'00" 00'27"
TITLE DESCRIPTION:
ST = Station No. : 11 to 6999, D = DISA
TK = Trunk No. : 01 to 10,
S = Status : # = Hold, * = Answered the hold, X = Cut off by toll restrictions.
Telephone Number : First 24 digits
Account : 8 digits in total
MM/DD : Month/Day
Begin_Time hh:mm : The start time of accessing the trunk line.
Duration_Tm hh:mm:ss : Time duration of the call.
Ring_Tm mm:ss : Incoming ring time.
Unit 00000 : Meter Pulse Count
CASE EXPLANATION:
CASE 1: October 2, 08:35 A.M., Station 112 made a call (telephone No. is 00116495256611) through line 1. The
call lasted 2 minutes and 35 seconds, Account code No. 12345678 was entered for the call and 12-meter pulses
were recorded.
CASE 2: October 2, 08:45 A.M., An incoming call on line 2, rang for 10 seconds, station 115 answered the call
and stored an Account No. 87654321.
CASE 3: October 2, 12:00 P.M., An incoming call through line 3, rang for 35 seconds, no one answered and the
call was abandoned.
CASE 4: October 2, 12:10 P.M., Station 112 made a Long Distance call through line 4 by Forced Account Code
1 and 23 meter pulses were recorded.
CASE 5: October 2, 12:30 P.M., Station 112 made a call by Forced Account Code but was denied because of a
wrong code.
CASE 6: October 2, 12:35 P.M., Station 116 made a call, which was restricted.
CASE 7: Line 1 was used by station 121 for 55 seconds then put on hold. One meter pulse was recorded
against this station for its section of the call.
CASE 8: The held line 1 was answered by station 117 and he occupied the line for 3 minutes and 10 seconds.
Four meter pulses were recorded against this station for its section of the call.
CASE 9: Incoming Line 3, using the DISA function, made an outside call 018220212 on line 5. The Duration time
is for line 5. 3 meter pulses were recorded for this call.
