Symptom
Countermeasures
Related Parts
When the following problem is occurred
If print too dark image, this kind of problem might be
happened. Refer to the manual 4.1.3.2 and adjust the
printing density. If the problem is not cleared, using
plus type driver and adjusting it until the problem is
removed.
When the card is out without printing
In case the Print Head is not properly installed or the
Print Head cable connection is bad, this kind of problem
might be happened. Refer to the manual 3.2.1 and
check the Print Head and cable connection state. If the
state is normal, the Print Head should be changed.
640257(ASSY S3,PRINT_HEAD_KPE)
If the card printing operation is not working except the card
movement
Please check the adaptor connection state. In the case
of using other adaptor, this fault may occur. Please
check the authorized adaptor is used .
5.4 Printing Quality
