4.1 Setup
Item Explanation
Yellow Level Set the yellow level value (Use only in board type 1, 2 )
Magenta Level Set the magnetic level value (Use only in board type 1, 2)
Cyan Level Set the cyan level value (Use board type 1, 2)
Black Level Set the black level value (Use board type 1, 2)
RMP +
Set the ribbon motor’s max torque value when a panel of ribbon is being printed on a card
Range : 2000 ~ 7000 (See 4.1.3.3)
RMP -
Set the ribbon motor’s min torque value when a panel of ribbon is being printed on a card
Range : 2000 ~ 7000 (See 4.1.3.3)
RMM+
Set the ribbon motor’s max torque value when a panel of ribbon is not being printed (RMM+
should be bigger than RMM–) Range : 4000 ~ 8000 (See 4.1.3.3)
RMM-
Set the ribbon motor’s min torque value when a panel of ribbon is not being printed (RMM–
should be smaller than RMM+) Range : 4000 ~ 8000 (See 4.1.3.3)
Auto Rotator Set Automatically Find proper Rotate Top and Rotator Bottom value
Rotate Top
Set the angle to be flat for the Flipper front side (Range : -30 ~ 30)
(The lower the value the more the angle) (See 4.1.3.4)
Rotate Bottom
Set the angle to be flat for the Flipper back side (Range : -30 ~ 30)
(The lower the value the more the angle) (See 4.1.3.4)
Reserved Not Use
Warming Up Display
Set the cycle of blinking LED button when heat the head on RW model. If the value is
increased, the LED blink slower.
Mag. Write Mode Set the track writing mode
Magnetic Space
Set the start position of magnetic data (Range : 10 ~ 30)
If the value is increased, the start position will be close to the end (See 4.1.3.5)
SBS Only Set the printer is only operated in the application which made by SDK (See 4.1.3.7)
• Expansion Setup Item
