SECTION 4
OPERATION
If Average Function is desired, configure
as follows:
OFF/ON
Toggles Average Function ON or OFF.
Cursor to Sample Number to enter
desired value. Range is 2 to 10.
If Upper Limit Function is desired,
configure as follows:
OFF/ON
Toggles Upper Limit Function ON or
OFF. Enter Limit Value. Range is 0 to
9.99 Radians.
If Lower Limit Function is desired,
configure as follows:
OFF/ON
Toggles Lower Limit Function ON or
OFF. Enter Limit Value. Range is 0 to
9.99 Radians.
If Alarm Function is desired, configure as
follows:
OFF/ON
Toggles Alarm Function ON or OFF.
When activated, alarm alerts over range
condition.
RETURN
Returns to RF Receive Operation
Screen.
If Mode Function is desired, configure as
follows:
NORM
Displays normal status bar.
BOTH
Displays negative to positive status bar.
RETURN
Returns to RF Receive Operation Screen.
Average:
Upper Limit:
ON
ON 28.0
2
Upper Limit:
Lower Limit:
ON
ON 12.0
28.0
Lower Limit:
Alarm:
ON
OFF
12.0
Lower Limit:
Alarm:
ON
OFF
12.0
Alarm:
Mode:
ON
NORM
