4-66
SECTION 4
OPERATION
4-6-2 AUDIO GENERATOR-2 OPERATION
Configure and operate Audio Generator-2
as follows:
GEN2
Toggles Audio Generator-2 ON and OFF.
o Enter Audio Tone Frequency. Range is
5.0 to 20000 Hz.
Select Shape of Wave as follows:
SINE
Selects Sine wave.
RAMP
Selects Ramp wave.
TRIANGLE
Selects Triangle wave.
SQUARE
Selects Square wave.
Set Level attenuation as follows:
X1
Selects X1 (times 1) level attenuation.
/10
Selects /10 (divide by 10) level attenuation.
T
e
n
Level selections range from 0 to 2.5 Vp in X1 (times 1) mode and 0 to
25.0 mVp in /10 (divide by 10) mode.
1000.0 Hz
SINEShape :
Freq :
1000.0 Hz
SINE
TONE
Level :
Shape :
Freq :
Format :
AUDIO GEN - 2 ON
0.00 Vp .000 Vrms
Level : 0.00 Vp .000 Vrms
