Page #248 background image
6-73
SECTION 6
OPTIONS
6-14-3 EDACS TRUNKING AUTOMATIC TEST
EDACS Trunking Automatic Test Screen consists of 4 main parts. Registration, Radio
Test, Repeater Test and Audio Test. Each Test is either ENABLED or DISABLED. This
state of the Automatic Test is referred to as the ‘Idle’ state. All Automatic Tests are run
with the UUT connected to the T/R port for both transmit and receive operations.
1. Registration
If ENABLED, Registration is the first test executed for the Automatic Test which
simply captures a login message from the radio and displays the Radio’s Group
and Logical ID’s along with the Control/Working channel frequencies.
2. Radio Test
If ENABLED, Radio Test executes and completes a Group Call sequence with a
radio and measures the Radio’s Transmitter Frequency Error, Transmitter RF
Power, High-Speed Data Deviation, Subaudible Data Deviation and Voice Peak
Deviation.
3. Repeater Test
If ENABLED, the Repeater Test measures the Repeater’s Transmitter Frequency
Error and Transmitter RF Power.
