6-27
SECTION 6
OPTIONS
6-12-4 TRANSMIT TRUNKING DATA BLOCK
23. Goto
Displays Repeater Number to use for
Status (25) set to Continuous. Must
match Home (27) for Mobile Radio to
unsquelch. Range is 1 to 31.
24. Group
Displays ID Code for Mobile Radio to
Test. Range is 1 to 255. Information is
passed when Repeater transmits to
access selected Mobile Radio.
25. Status
Displays Status for Repeater for testing Mobile Radio. Set to FREE (Free Home
Repeater), BUSY (Busy Home Repeater), CONT (Continuous transmit by Home
Repeater) and DISCN (Disconnect Repeater-Mobile link). If CONT is desired,
Goto (23) must match Home (27).
26. Free
Displays Repeater Number used for Mobile transmission with Status (25) set to
BUSY. Free Repeater Channel on LTR Trunking Auxiliary Setup Screen
(paragraph 6-12-4) must also be set for proper operation. Range is 1 to 31.
27. Home
Displays Home Repeater Number used for testing Mobile Radios. Range is 1 to
31.
28. Area
Displays Proximity Switch setting. Range is 1 or 0.
00607237
Group
GotoArea
Home
Free
151
9
0
5
9 Status CONT
23
24
2526
27
28
